    Basic Info.
    Model:
    A002
    Processing customization:
    No
    Material:
    Stainless steel
    Core diameter:
    3.2 mm
    Types:
    Stainless steel electrode
    Drug coating properties:
    Acid electrode
    Diameter:
    3.2 mm
    Length:
    350 mm
    Welding current:
    180 - 250 A A
    Current amplitude:
    250 A
    Operating temperature:
    200 ℃
    Applicable scope:
    stainless steel welding
    Hardness HRC:
    100
    Product Description

    A002 stainless steel electrode E308L-16 electrode is a very commonultra-low carbon stainless steel electrode, widely used in industrial welding.
    • Type of coating: It usestitanium calcium type coating (also described as rutile type), usually green or white.
    • Welding performance: The advantage of this electrode is easy to use. It is AC/DC dual-use (AC/DC), arc combustion stability, small splash, weld formation is very beautiful, easy to remove slag.
    •
    • element C (carbon) Cr (chromium) Ni (Nickel) Mn (manganese) Si (silicon) S/P
      Content (%) ≤ 0.04 18.0~21.0 9.0~11.0 0.5~2.5 ≤ 0.90 ≤ 0.030/≤0.040
    •
    • Material matching: mainly used for welding00Cr19Ni10 (i.e. 304L) stainless steel structure.
    • Alternative applications: It can also be used for welding stainless steels suchas 0Cr19Ni11Ti(i.e. 321), especially when the working temperature is lower than300 ° C.
    • Industry application: Widely used in synthetic fiber, fertilizer, petroleum, chemical equipment manufacturing.
    • Special scenarios: Due to its high density of weld metal, it is also suitable for occasions with high requirements for air tightness, and even in some ultra-low temperature (such as-196℃) equipment that does not require extreme requirements.
    • Pre-weld drying: This is the most critical step. The electrode usually needs to be baked at250℃~300℃for 1 hourbefore use, and then used with baking to prevent moisture from causing pores in the weld.
    • Cleaning treatment: rust, oil stain and moisture on the surface of weldment must be thoroughly removed before welding.
    • Control heat:
      • Low current,short arc operation is recommended.
      • Minimize heat input and avoid excessive electrode swing.
      • The interlayer temperature * is well controlledbelow 150 ° C, which can better exert its intergranular corrosion resistance.
